Benefits and Features
Apollo Inffratech Private Limited – one of India’s fastest growing concrete solutions provider has now formed a joint venture company Apollo Carmix Equipments Private Limited with Metalgalante(Italy) that invented and developed Carmix, the no. 1 in the 4×4 Self-Loading Concrete Mixer.Thanks to its over 4 decades of experience, CARMIX represents world-wide the Ideal Solution to produce high-quality cost-effective concrete wherever and whenever needed.Carmix works efficiently in over 150 countries and now we proudly say that the same equipments are manufactured & distributed in India.
MIXING UNIT:
Drum Volume : 5200 liters. Capacity: 4 m3 per batch, (Concrete output @ 75 to 80% of the rated capacity). Double mixing screws, cover for emergency unloading. Drum rotation by hydraulic motor and planetary reducers. Mixing and discharging speed independent from r.p.m. of diesel engine. Discharging by reversing drum. The mixing unit is slewing hydraulic through 270° for high discharge over 2m. on the four sides of the vehicle.
ENGINE:
Kirloskar Oil Ltd Model : 4R 01040 TA, BS III, Water-Cooled four stroke turbo charge diesel engine. Ratings : 110 HP@2500 rpm. Engine mounted transversal on the rear.
SALIENT FEATURES
- Capacity: 4 m' per batch
- Concrete Output : 85- 90% of the rated capacity.
(Considering 1 cum = 2400 kg. MAX) Slump SI Operation is user-friendly - Compact & economic
- Low Maintenance Cost
- High pressure water pump
- 4 Wheel drive and 4 Wheel steer
- Electronic weighing system with printer
- Efficient and reliable after-sales service
- Ideal solution, whenever & wherever small quantity of concrete is required
OPTIONAL
- High Pressure Washing System
- Additive Tank
- GPS System
- Load Cell System
Photos
