Due to 3 Batch System Plant gives 90% of the theoretical output Claimed
Robust and Steady Structure made from square and rectangular tube for longer durability and protection from corrosion
PLC system improves the accuracy of Weighing System as it does not require extra weighing indicators
Quick Exhaust Valve fitted with all Pneumatic Cylinders to maintain the accuracy in weighing system
Feeder Screen to protect from oversized aggregate and Sand
MPCB are provided for all Electrical motor Safety
Cover is provided to every electrical motor for protection against dust and water

Output/hr	30 m³
Aggregate Storage Facility	In Line Bin
No. of Aggregate Storage Compartments	4 Standard / 5 Optional
Aggregate Bins Capacity	30 m³
Mixer	Twin Shaft/Pan/Planetary(750/500)
Control System	PLC Based
Plant Designation	Charging Conveyor
Cement/Fly Ash Silo	Optional

Output/hr	45 m³	60 m³	75 m³
Aggregate Storage Facility	In Line Bin	In Line Bin	In Line Bin
No. of Aggregate Storage Compartments	4 Standard / 5 Optional	4 Standard / 5 Optional	4 Standard / 5 Optional
Aggregate Bins Capacity	45 m³	60 m³	60 m³
Mixer	Planetary/Twin Shaft(1250/750)	Planetary/Twin Shaft(1500/1000)	Planetary/Twin Shaft(1750/1250)
Control System	PLC Based	PLC Based	PLC Based
Plant Designation	Charging Conveyor	Charging Conveyor	Charging Conveyor
Cement/Fly Ash Silo	Optional	Optional	Optional

Output/hr	90 m³	100 m³	120 m³
Aggregate Storage Facility	In Line Bin	In Line Bin	In Line Bin
No. of Aggregate Storage Compartments	4 / 5	4 / 5	4 / 5 / 6
Aggregate Bins Capacity	80 m³	100 m³	100 m³
Mixer	Planetary/Twin Shaft(2250/1500)	Planetary/Twin Shaft(3000/2000)	Planetary/Twin Shaft(4500/3000)
Control System	PLC Based	PLC Based	PLC Based
Plant Designation	Charging Conveyor	Charging Conveyor	Charging Conveyor
Cement/Fly Ash Silo	Optional	Optional	Optional
